ROV Systems
V8 L3000
3000 m
Depth rating
270 kg
Weight in air
2,5 knots
Speed (Fwd/Bwd)
ROV systems
V8 L3000
For customers who require an inspection class ROV that dives deeper and carries a greater payload Ocean Modules offers the V8 L3000. The V8 L3000 uses the same control system as the M500 and therefore has same manoeuvrability and stability. The V8 L3000 has a maximum diving depth of 3000 meters and numerous electrical and data interfaces. With fibre optic communications and configurable communications ports that enable interfaces for Ethernet, Serial ports RS 232/485, HD-video and analogue data.
Virtual serial ports make it simple to route data between subsystems and sensors on the ROV and processing software on the surface
Product overview
| Size | Standard size: 1190 x 840 x 890 mm |
| Weight in air | Approx. 270 kg |
| Bollard pull | 56 kg |
| Payload (without skid) | Standard approximately 30 kg, can be customised. |
| Thrusters | 8 x 750W Brushless (thruster 110) thrusters |
| Control system | 6 degrees of freedom |
| Speed (Fwd/Bwd) | 2,5 knots |
| Depth rating | 3000 m |
| Data | 12x RS232 12x RS485 4x Gbit ethernet |
| Operating temperature range | -5° to 40°C |
| Storage temperature range | -25° to 50°C |
Suitable for observation and light work
In the world of work class ROVs, the L3000 is small. However, given its versatility thanks to the 360DOF control system it can perform many tasks which previously only larger vehicles could accomplish, which makes it very economically viable. Check out the webshop below for more information.
Example usage
Check out our case studies for reference use cases.
Versatile and capable, yet relatively small footprint
With its relatively small foot print the L3000 is simple to integrate onto your vessel. The L3000 is suitable for any inspection job as well as light work. It can be equipped with sensors previously requiering larger vehicles, such as the TSS350 for cable tracking. If a large array of equipment is needed, the L3000 can be equipped with a skid. As standard, it is already equipped with a large array of interfaces for data acquisition such as RS232/485 and gbit ethernet.
